800wog Y Type Check Valve
Y Type Check valve 800WOGFeaturesVarious Thread Standards AvailableSuitable for installation in horizontal and verticalUsing dewaxing precision castingProduct standardDesign: ASME B16.34Wall Thickness: ASME B16.34Pipe Thread: ASME B1.20.1, BS21, DIN 2999/259, ISO 228/1, JIS B 0203, ISO 7/1Inspection......
Send Inquiry
Product Description
Y Type Check valve 800WOG
Features
Various Thread Standards Available
Suitable for installation in horizontal and vertical
Using dewaxing precision casting
Product standard
Design: ASME B16.34
Wall Thickness: ASME B16.34
Pipe Thread: ASME B1.20.1, BS21, DIN 2999/259, ISO 228/1, JIS B 0203, ISO 7/1
Inspection & Testing: MSS SP-110, EN 1226
Features
Various Thread Standards Available
Suitable for installation in horizontal and vertical
Using dewaxing precision casting
Product standard
Design: ASME B16.34
Wall Thickness: ASME B16.34
Pipe Thread: ASME B1.20.1, BS21, DIN 2999/259, ISO 228/1, JIS B 0203, ISO 7/1
Inspection & Testing: MSS SP-110, EN 1226
| No. | Parts name | Material | |
| ANSI/JIS/DIN | ANSI/JIS/DIN | ||
| 1 | Body | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 2 | Compression ring | SUS304 | |
| 3 | Cap gasket | PTFE/RPTFE | |
| 4 | screw | A193-B8 | |
| 5 | Disc | SUS304 | |
| 6 | Spring | SUS304 | |
| 7 | Cap | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 8 | Cap gasket | PTFE/RPTFE | |
| Size | d | L | H |
| 1/2" | 17.5 | 67 | 44.7 |
| 3/4" | 23 | 75 | 52.1 |
| 1" | 29 | 90 | 65.7 |
| 1-1/4" | 38 | 110 | 70 |
| 1-1/2" | 43.5 | 120 | 79.5 |
| 2" | 55 | 140 | 95.5 |
| 2-/2" | 69 | 190 | 125 |
| 3 | 81.5 | 205 | 144.5 |
