Non-Rising Stem Resilient Sealed Gate Valve
Product DescriptionU ideal valvesType: Butterfly valves, Gate valves, Check valves, Global valves, Y strainer, Level gauge, Flow meterMain materials:NameMaterialBonnetCast iron, ductile iron, cast ste......
Send Inquiry
Product Description
Product Description
U ideal valves
Type: Butterfly valves, Gate valves, Check valves, Global valves, Y strainer, Level gauge, Flow meter
Main materials:
Name
Material
Bonnet
Cast iron, ductile iron, cast steel
Body
Cast iron, ductile iron, cast steel
Disc
Ductile iron (EPDM or NBR)
Stem
Stainless steel
Seal ring
NBR
Screw
Stainless steel
Design specification: GB/T 12234
Face to face: GB/T 12221
Connection flange: GB/T 17241.6 GB9113
Text and inspection: GB13927 AP1598
Related products: Gate Valve Ball Valve Check Valve Globe Valve Butterfly Valve Knife Gate Valve Cryogenic Valve Water valve two or three ways valve hydraulic valve float valve pressure reducing valve.
U ideal valves
Type: Butterfly valves, Gate valves, Check valves, Global valves, Y strainer, Level gauge, Flow meter
Main materials:
Name
Material
Bonnet
Cast iron, ductile iron, cast steel
Body
Cast iron, ductile iron, cast steel
Disc
Ductile iron (EPDM or NBR)
Stem
Stainless steel
Seal ring
NBR
Screw
Stainless steel
Design specification: GB/T 12234
Face to face: GB/T 12221
Connection flange: GB/T 17241.6 GB9113
Text and inspection: GB13927 AP1598
Related products: Gate Valve Ball Valve Check Valve Globe Valve Butterfly Valve Knife Gate Valve Cryogenic Valve Water valve two or three ways valve hydraulic valve float valve pressure reducing valve.
| Detailed Description: | |
| Series | Non-rising stem resilient seated gate valve |
| Size: | DN40-DN600 |
| Design standard: | GB/T 12232-2005 DIN3352, EN593, MSS SP-67 |
| Pressure standard: | GB/T 13927-1992, API598 |
| Face to face: | DIN3202 F4, F5, BS5155 |
| Flange standard: | DIN2532, DIN2533 |
| Body: | CI/DI/WCB/ALB/CF8/CF8M |
| Disc: | DI/ALB/Rubber lined Disc/1.2501/1.4529/CF8/Hastelloy Alloy/Monel |
| Stem: | SS416/SS304/SS431/17-4PH |
| Seat: | NBR/Hypalon/EPDM/Neoprene/NR/Wear-Resistant EPDM/Viton/Silicon/Heat-Resistant EPDM/White EPDM/EPDM()/PTFE |
| Suitable temperature: | -10~90 |
| Medium: | Fresh water, sewage, sea water, air, vapor, food, medicine, oils, alkalis, salt etc. |
