4V110 -06 Pneumatic Solenoid Valve
Model3V110~4103V120~4203A110~4103A120~420Position and way NO.Two-position Three-wayWorking Medium40Micron Filtered AirMotion PatternInner Guide TypeWorking-pressure0.15~0.8MpaMax Pressure Resistance1.2MpaOperating Temperature5~50°CVoltage Range-10%~+10%Power ConsumptionAC:4.5VA DC:3WInsulat......
Send Inquiry
Product Description
Model | 3V110~410 | 3V120~420 | 3A110~410 | 3A120~420 |
Position and way NO. | Two-position Three-way | |||
Working Medium | 40Micron Filtered Air | |||
Motion Pattern | Inner Guide Type | |||
Working-pressure | 0.15~0.8Mpa | |||
Max Pressure Resistance | 1.2Mpa | |||
Operating Temperature | 5~50°C | |||
Voltage Range | -10%~+10% | |||
Power Consumption | AC:4.5VA DC:3W | |||
Insulation &Protection Class | F Class.IP65 | |||
Electrical entry | Lead Wire or Connector type | |||
Highest Action Frequency | 5Cycle/Second | |||
Response time | 0.05Second | |||
