Vatac Cast Iron Resilient Seated Gate Valve
Vatac Cast Iron Resilient Seated Gate Valve Conform to API 600, ASME B16.34, They are tested according to API 598, and marked as per MSS SP-25.1. Construction is as follows: - Full Port or Standard Port- Outside Screw and Yoke(OS&Y)- Bolted Bonnet with spiral-would gasket, threaded and seal we......
Send Inquiry
Product Description
Vatac Cast Iron Resilient Seated Gate Valve Conform to API 600, ASME B16.34, They are tested according to API 598, and marked as per MSS SP-25.
1. Construction is as follows:
2. Main Part & Materials
3. Normal Pressure Rating
PN10~PN16, CLASS150
4. Normal Size Range
DN50~DN900, 2"~36"
1. Construction is as follows:
- Full Port or Standard Port | |||||||
| - Outside Screw and Yoke(OS&Y) | |||||||
| - Bolted Bonnet with spiral-would gasket, threaded and seal welded bonnet and threaded and pressure seal bonnet | |||||||
| - Backseat | |||||||
| - Solid or Flexible Wedge | |||||||
| - Butt Weld Ends to ASME B16.25 | |||||||
| - Flanged Ends to ASME B16.5 and B16.47 |
2. Main Part & Materials
Part Names | Part Materials | |||||||
| Body | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M | C83600/C95800 |
| Bonnet | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M | C83600/C95800 |
| Disc/Ball/Wedge | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M | C83600/C95800 |
| Stem | F6a | F304 | F6a | F304 | F316 | F304L | F316L | C83600/C95800 |
| Seat/Seat Ring | 13%Cr | SS304 | 13%Cr | SS304 | SS316 | SS304L | SS316L | C83600/C95800 |
| Packing | Graphite/PTFE | |||||||
| Gasket | SS304+Graphite/SS304+Graphite | |||||||
| Bolts/Nuts | B7/2H | L7/4 | B16/4 | B8/8 | B8M/8M | B8/8 | B8M/8M | B8M/8M |
| Suitable Medium | W.O.G etc. | HNO3, CH3OOH etc. | Sea Water etc. | |||||
| Suitable Temperature | -29~425 °C | -46~340 °C | -46~340 °C | -196~427 °C | -196~427 °C | -196~427 °C | -196~427 °C | -29~220 °C |
3. Normal Pressure Rating
PN10~PN16, CLASS150
4. Normal Size Range
DN50~DN900, 2"~36"
