Acetylene ( C2H2 ) Cylinder Valve Cga200 with Spanner
Acetylene(C2H2) Cylinder Valve CGA200 With Spanner, CGA200 Acetylene Valve for C2H2 Gas Cylinders, acetylene(C2H2) Cylinder Valve CGA200 for Acetylene Cylinders & Acetylene Supply System.Specs of CGA200 Acetylene Valves:-Suitable Medium: C2H2(acetylene);-W. P. (Mpa): 3;-DN(mm): Φ 3 mm;-O......
Send Inquiry
Product Description
Acetylene(C2H2) Cylinder Valve CGA200 With Spanner, CGA200 Acetylene Valve for C2H2 Gas Cylinders, acetylene(C2H2) Cylinder Valve CGA200 for Acetylene Cylinders & Acetylene Supply System.
Specs of CGA200 Acetylene Valves:
-Suitable Medium: C2H2(acetylene);
-W. P. (Mpa): 3;
-DN(mm): Φ 3 mm;
-Outlet Joint thread: CGA200
-Inlet joint thread ( thread to cylinder): 3/8-18-ngt
-Safety device: 100deg± 5deg
-Frame modality: Movable flap type;
-Packaging Details: 25PCS/carton;
-Delivery Detail: Within 15 days;
*Keywords: Dissolved acetylene cylinder valves CGA200, Acetylene(C2H2) Cylinder Valve CGA200, Acetylene Valves CGA200, C2H2 valves, acetylene cylinder valves, CGA200, gas valves, brass valves CGA200, gas cylinder valves.
A valve is a device that regulates, directs or controls the flow of a fluid (gases, liquids, fluidized solids, or slurries) by opening, closing, or partially obstructing various passageways. Valves are technically valves fittings, but are usually discussed as a separate category. In an open valve, fluid flows in a direction from higher pressure to lower pressure.
Valves have many uses, including controlling water for Irrigation, industrial uses for controlling processes, residential uses such as on / off & pressure control to dish and clothes washers & taps in the home. Even aerosols have a tiny valve built in. Valves are also used in the military & transport sectors.
*About Us:
We are a professional manufacturer and supplier of Gas Cylinders Regulators, Oxygen Flowmeters, Medical Oxygen Flow Regulators, Medical Oxygen Kits, Oxygen Intake Devices, Gas O2 Valves, Medical Pin Index Valves, Medical Gas O2 Supply System Products, Gas O2 Cylinder Trolleys, Gas O2 Outlets, Ceiling Medical Pendants, Medical Gas Oxygen Respiratory Products and etc.
*Advantages We Have:
-1).Original Manuacturer: Being a professional manufacturer, we have professional equipments for our manufactureing products, including Punch Machines, CNC Machines, and etc.;
-2)Large Output capability: We have the capability to produce more than 50, 000PCS of Medical Oxygen Flowmeters each month;
-3)Quality Control: With ISO13485 Quality Management system; All products have been tested before out of factory;
-4)Cost Advantages: We have cost advantage because our professional and scale economy;
-5)Series: We have different series and models, for different standards in different countries;
-6)Small order can be acceptable: M. O. Q. =50PCS;
-7)Exporting experience: We have over 5 years' experience for exporting.
NOTES:
-a). Various types of acetylene gas cylinder valves,cylinder caps,steel valve guards can be optional;
-b).We have many advantages of satisfying our potential customers' MIXED needs of different sizes of HP steel gas(O2/Helium/Argon/CO2/N2) cylinders raning from 0.2L~68L @15Mpa/20Mpa & ISO3807-1/2 Dissolved Acetylene Cylinders(2L~60L).
Anyway,should you have any intersts or some more info needed on our medical gas cylinders & allied gas items(gas cylinder valves,gas regulators,medical hospital central oxygen system products),you are really welcome to enquire us anytime!
Key Contact: Ethan Liu (Exp. Mgr)
URL: http://cbmtech.en.made-in-china.com ; http://cbmtech.en.made-in-china.com
Specs of CGA200 Acetylene Valves:
-Suitable Medium: C2H2(acetylene);
-W. P. (Mpa): 3;
-DN(mm): Φ 3 mm;
-Outlet Joint thread: CGA200
-Inlet joint thread ( thread to cylinder): 3/8-18-ngt
-Safety device: 100deg± 5deg
-Frame modality: Movable flap type;
-Packaging Details: 25PCS/carton;
-Delivery Detail: Within 15 days;
*Keywords: Dissolved acetylene cylinder valves CGA200, Acetylene(C2H2) Cylinder Valve CGA200, Acetylene Valves CGA200, C2H2 valves, acetylene cylinder valves, CGA200, gas valves, brass valves CGA200, gas cylinder valves.
A valve is a device that regulates, directs or controls the flow of a fluid (gases, liquids, fluidized solids, or slurries) by opening, closing, or partially obstructing various passageways. Valves are technically valves fittings, but are usually discussed as a separate category. In an open valve, fluid flows in a direction from higher pressure to lower pressure.
Valves have many uses, including controlling water for Irrigation, industrial uses for controlling processes, residential uses such as on / off & pressure control to dish and clothes washers & taps in the home. Even aerosols have a tiny valve built in. Valves are also used in the military & transport sectors.
| NO. | Type No. | Produce Name | suitable Medium | PN (Mpa) | DN (mm) | Outlet thread(mm) | Jiont Thread to cylinder (mm) | Temp./Pressure of safety device |
| 1 | CGA200 | Brass neddle type cylinder valve for C2H2 | C2H2(acetylene) | 3 | 3 | CGA200 | 3/8-18-NGT | 100deg±5deg |
| 2 | CGA300(QF-70) | Brass neddle type cylinder valve for C2H2 | C2H2(acetylene) | 3 | 4 | .825-14NGO-RH | 3/4-14-NGT | |
| 3 | CGA320 | Brass flapper type cylinder valve for CO2 | CO2 | 15 | 4 | CGA320 | 3/4-14-NGT | 21±1.5 |
| 4 | CGA326 | Brass flapper type cylinder valve for N2O | N2O | 15 | 4 | CGA326 | GB8335 PZ27.8 | 21±1.5 |
| 5 | CGA350 | Brass coupling type cylinder valve for CO2 | CO2 | 15 | 7 | CGA350 | 3/4-14-NGT | 21±1.5 |
| 6 | CGA510(QF-72) | Brass coupling type cylinder valve for C2H2 | C2H2(acetylene) | 3 | 4 | Female Thread CGA510 | 1-11 1/2 -NGT | |
| 7 | CGA510-1(QF-71) | Brass flapper type cylinder valve for C2H2 | C2H2(acetylene) | 3 | 4 | Female Thread885-14NG0-LH | 3/4-14-NGT | |
| 8 | CGA520 | Brass neddle type cylinder valve for C2H2 | C2H2(acetylene) | 3 | 3 | CGA520 | 3/8-18-NGT | 100deg±5deg |
| 9 | CGA540 | Brass flapper type cylinder valve for O2(oxygen) | O2,N2,Air | 15 | 4 | CGA540 | 3/4-14-NGT | 21±1.5 |
| 10 | CGA555 | Brass flapper type cylinder valve for N2 | N2,O2,Air | 15 | 4 | CGA555 | GB8335 PZ27.8 | 21±1.5 |
| 11 | CGA580 | Brass flapper type cylinder valve for H2 | He,Ne,Ar,Kr,Xe | 15 | 4 | Female Thread CGA580 | 1-11 1/2 -NGT | 21±1.5 |
| 12 | CGA590 | Brass flapper type cylinder valve for O2(oxygen) | O2,N2,Air | 15 | 3 | Female Thread CGA590 | 3/4-14-NGT | |
| 13 | CGA870A | Cylinder valve for O2(oxygen) | O2 | 15 | 1.5 | 7 clip2-4.7 fixed mpin | 3/4-16-UNF | steelcylinder21-23.2 Aluminum cylinder22.9-25.5 73deg±3deg |
| 14 | CGA910 | Cylinder valve for N20 | N20 | 15 | 2.5 | 7 clip2-4.7 fixed mpin | 3/4-14-NGT | |
| 15 | CGA670 | Brass neddle type cylinder valve for mixed gas | mixed gas(Cl2,etc) | 2 | 7 | Male thread CGA670 | 3/4-14-NGT |
*About Us:
We are a professional manufacturer and supplier of Gas Cylinders Regulators, Oxygen Flowmeters, Medical Oxygen Flow Regulators, Medical Oxygen Kits, Oxygen Intake Devices, Gas O2 Valves, Medical Pin Index Valves, Medical Gas O2 Supply System Products, Gas O2 Cylinder Trolleys, Gas O2 Outlets, Ceiling Medical Pendants, Medical Gas Oxygen Respiratory Products and etc.
*Advantages We Have:
-1).Original Manuacturer: Being a professional manufacturer, we have professional equipments for our manufactureing products, including Punch Machines, CNC Machines, and etc.;
-2)Large Output capability: We have the capability to produce more than 50, 000PCS of Medical Oxygen Flowmeters each month;
-3)Quality Control: With ISO13485 Quality Management system; All products have been tested before out of factory;
-4)Cost Advantages: We have cost advantage because our professional and scale economy;
-5)Series: We have different series and models, for different standards in different countries;
-6)Small order can be acceptable: M. O. Q. =50PCS;
-7)Exporting experience: We have over 5 years' experience for exporting.
NOTES:
-a). Various types of acetylene gas cylinder valves,cylinder caps,steel valve guards can be optional;
-b).We have many advantages of satisfying our potential customers' MIXED needs of different sizes of HP steel gas(O2/Helium/Argon/CO2/N2) cylinders raning from 0.2L~68L @15Mpa/20Mpa & ISO3807-1/2 Dissolved Acetylene Cylinders(2L~60L).
Anyway,should you have any intersts or some more info needed on our medical gas cylinders & allied gas items(gas cylinder valves,gas regulators,medical hospital central oxygen system products),you are really welcome to enquire us anytime!
Key Contact: Ethan Liu (Exp. Mgr)
URL: http://cbmtech.en.made-in-china.com ; http://cbmtech.en.made-in-china.com
